产品形貌Product description
◆FA5-3S/FA5-6S?系列是一款通用型扳机电子调速开关，其中FA5-6S系列是升级款，可以遭受更大的电流攻击，集成防尘功效，普遍应用于种种电动工具，如: 6mm电钻、10mm电钻、攻击钻、攻击螺丝起子、电锤、曲线锯、搅拌器、平板砂光机等, 也可用于吊磨机的脚踏开关等 ？赜卸嘀职饣⑺ズ筒Ω丝梢匝≡，也可以凭证客户要求举行定制。
◆FA5-3S/FA5-6S?series are one general type variable speed trigger switches with by-pass contact, specially?FA5-6S?is high rated type,?integrated dustproof, for popular used in portable power-tools such as: 6mm Drills, 10mm Drills, Impact Drills, Impact Screw Drivers, Rotary Hammers, Jig Saws, Electric Mixers, Orbit Sanders, etc. Also used for Foot switch of Hanging Carving Machine.
产品特征Features
◆可选带以下功效 Optional with following functions:
→全波调速 Full-wave speed control
→半波调速 Half-wave speed control
→On-Off通断功效 On-Off version
→On-Off通断功效带线性电位器输出 On-off version with Passive linear potentiometer
→正转或反转限速 Speed limited in forward or reverse
◆可选带以下锁定类型 Optional with following lock types:
→无锁 No Lock
→闭合锁定 Lock-on
◆可选带以下附件 Optional with the accessories as follows:
→初始电压微调理旋钮 Knob for adjusting start voltage
→扳机旋钮 Dial wheel of Trigger
→包软胶扳机 Trigger covered with rubber (overmolding)
◆开关内部电子部分在响应使用中一并做过相关测试，本开关适合做二类用具开关使用.
◆The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
端子类型Terminals
◆输入端 Input side:
→接线柱端子 Pillar terminals φ=3mm
◆输出端和换向盒端 Output side and Reversing Box side:
→插入式端子可插入沾锡导线，带插片端子导线或铜包头导线
→Push-in terminals for soldered strands, strands with end sleeve or strands with end claws.
★本产品荣获适用新型专利，专利号：ZL201920465988.7
★Utility Model patented with the no. is?ZL201920465988.7
电气参数和认证 Electric Rating and Certification
