产品形貌Product description
◆FA1-10B, FA1-10D系列是一款通用性的大电流扳机开关，集成防尘功效，内部为快速行动结构，适合大功率的台式和手持式电动工具及园林工具，如：型材切割机、斜切锯(介铝机)、150、180和230角磨机、抛光机、电圆锯、电锤、电镐、电链锯等。
◆FA1-10B, FA1-10D series are general type high rated trigger switches, integrated dustproof, with snap-action structure, for used in high rated bench top, portable power-tools and gerdening tools such as Cut-off Machines, Miter Saws, 150mm, 180mm and 230mm Angle Grinders, Polishers, Circular Saws, Rotary Hammers, Demolition Hammers, Electric Chain Saws, etc.
产品特征Features
◆可选带以下功效 Optional with following function:
→双极？ Double Pole Normally Open (DPNO)
→一极？，另一极常闭 One Pole Normally Open, the other normally close
→带软胶扳机 Trigger covered with rubber (Overmolding)
◆可选带以下锁定类型 Optional with following lock types:
→无锁 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off
→断开锁定带闭合锁定 Lock-off with lock-on
手艺数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4 / 1E4
→最大攻击电流 Max. Inrush current at 250V90A
→最大攻击电流 Max. Inrush current at 125V132A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情形温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护用具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→4×螺钉端子 Screw terminals M3.5
→4×插片端子 Plug terminals 6.3×0.8mm
★本产品荣获适用新型专利，专利号：ZL202021631305.X
★Utility Model patented with the no. is ZL202021631305.X
电气参数和认证 Electric Rating and Certification
