FA5-10C-A1

FA5-10C防尘快速行动扳机开关

FA5-10C series Dustproof Snap-action Trigger Switches

产品形貌Product description

◆FA5-10C 系列是一款专用型的扳机开关 ，集成防尘功效 ，适合一样平常功率的台式和手持式电动工具及园林工具 ，如：型材切割机、斜切锯(介铝机)、125、150和180角向磨光机、抛光机、电圆锯、电锤、电镐、电链锯等 。
◆FA5-10C series are general type trigger switches, integrated dustproof, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm, 150mm and 180mm Angle Grinders, Circular Saws, Polishers, Rotary Hammers, Demolition Hammers, Electric Chain Saws, etc.

产品特征Features

◆可选带以下锁定类型 Optional with following lock types:
→无锁定 No Lock

→闭合锁定 Lock-on

→断开锁定 Lock-off

手艺数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V90A
→最大攻击电流 Max. Inrush current at 127V120A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情形温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护用具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→螺钉端子 Screw terminals M4

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
